The parking garage was constructed using a post tensioned form of concrete placement with steel reinforcement. Traditionally parking garages require beams be placed approximately every 40 feet. By implementing this system the distance between beams was expanded to approximately 60 feet between each beam giving the space a more open feeling and less restrictive traffic flow pattern. This enables the most cost effective return for optimum parking of vehicles.

Built on the site of the single grade level employee parking lot. The new three level parking garage can provide parking for up to 625 cars. Should the hospital ever decide to expand, the structure was designed to accommodate an additional two levels.

Features of the parking garage include pedestrian bridge which connects to the hospital as well as to an existing lot on the other side of the tracks. A fire alarm system complete with heat detection units as well as a sprinkler system was installed. To provide employees with access to the parking garage a card access loop was developed.

PROJECT TYPE

Construction of a new parking garage


DESCRIPTION

Three level parking garage


OWNER

Winthrop University Hospital


ARCHITECT

Sidney Bowne, and Carl Walker Inc.


DELIVERY METHOD

NA


CONSTRUCTION COST

$9.6 million


SIZE

NA
